3033593 Excavator Transmission Cover for Hitachi ZX330-5G

Part number 3033593 is a genuine gearbox cover produced by Hitachi Construction Machinery in Japan. This component is the end cover or inspection cover on the side of the gearbox (such as the walking and rotating gearbox), mainly used for sealing, dust prevention, supporting bearings, and forming a lubricating oil chamber. Its universal model usually covers ZX330-5G same platform models, and may also be applicable to 5G series excavators with similar tonnage and gearbox design such as ZX350-5G and ZX370-5G. As the core sealing and supporting component of the original factory, its installation hole position, bearing seat hole, sealing surface are completely matched with the gearbox housing.

This product is a circular end cap made of high-strength cast iron precision machining. The main body is disc-shaped, with a large through-hole in the center for installing bearings or passing through shaft components. Multiple bolt installation holes are evenly distributed on the edges. The material is gray cast iron (such as HT250) or ductile iron, which has high rigidity and good shock absorption. The surface has undergone rust prevention treatment and appears dark gray with a black tint. The mating surface with the gearbox housing and the central bearing hole have been precision machined and ground to ensure flatness and roundness, achieving reliable sealing and precise bearing positioning. The end cover usually integrates oil seal installation grooves and O-ring sealing grooves. Its core function is to provide stable support for the rotating shaft while sealing the gear oil inside the gearbox, and prevent external mud, water, and dust from entering.

Installation specifications (key in sealing): 1 Thoroughly clean: Before installation, the joint surface of the gearbox housing, the inner and outer surfaces of the end cover, and all bolt holes must be thoroughly cleaned with cleaning agent and a lint free cloth to ensure that there is no oil stains, rust, or residual old sealant. 2. Replace seals: It is necessary to replace the new oil seal (if the center hole has an oil seal) and O-ring/gasket, and apply an appropriate amount of grease or transmission oil on the seals for installation. 3. Uniform tightening: Align the end cap with the positioning pin and place it steadily. Use a torque wrench to tighten the bolts 2-3 times in diagonal order to the specified torque (usually 40-70 N · m, please refer to the maintenance manual for details).
